Mild Steel Wire Dust Collector Filter Cage Silicon Coating

Product Categories

zhangjiagang 17s commerce co.,ltd

Contact Now

Brand Name : 17s

Model Number : 17SRC011

Certification : ISO

Place of Origin : China

MOQ : negotiable

Price : negotiable

Supply Ability : TBD

Delivery Time : TBD

Packaging Details : steel crates

Material : Carbon Steel

Finish Treatment : silicon Coating

Venturi : no

Diameter : Customized

Vertical Wires No. : 8 To 24 PCS

Top Cap : U shape weld to cage

Vertical Wire Thickness : 3-4mm

Contact Now

Silicon Coating Dust Collect Filter Cage Anti-Corrosion Coating Cage Mild Steel Wire Bag Cage

Instruction

Style	silicon coating round filter cage
Item	17SRC011
Material	Q235 wild steel
Diameter	90-250		mm
Vertical / Longitudinal Wire	Number	8-24	pcs
Vertical / Longitudinal Wire	Thickness	3-5	mm
Support / Latitudinal Ring	Type	round
	Thickness	3.5-6	mm
	Distance	150-250	mm
Length	TBD		mm
Structure	one section
Joining Method	no
Top Cap	Type	U shape top cap
	Size	per cage size	mm
	Thickness	1-1.2	mm
	Fix	weld to cage
Venturi	Size	no	mm
	Thickness	no	mm
	Fix	no
Bottom Cap	Type	punch plate
	Size	per cage diameter	mm
	Thickness	1	mm
	Fix	weld to cage
Finishing	Type	silicon coating
	Thickness	80-140	um
	Color	black
Pack	steel crate

Applications
